BLUE SEA SYSTEMS Marine Battery Chargers P12 40A Battery Charger

A fully programmable charger that can handle large and small batteries at the same time.

Battery technology is constantly changing. Having a charger that can respond to these changes will maximize the lifespan of your batteries. The P12 is ideal for keeping up with battery technology. Blue Sea Systems pre-programs the P12 with conventional bulk, absorption, and float stages for the four most common battery types. However, these chargers can be user programmed and meet the specific demands of manufacturers and their developing technology. Unique to the P12 is a fourth stage, referred to as “pre-float”, that increases the lifespan of smaller batteries by preventing them from being overcharged while larger batteries are still in the bulk or absorption stage.

An easy to read and intuitive digital display makes programming the charger straightforward. An available remote allows you to monitor charging status from the nav-station or helm. Blue Sea Systems designed the P12 chargers to work with automatic charge relays (ACR) to maintain battery bank separation while charging. Temperature compensation tailors charge voltage to individual battery condition to maximize their performance. The P12 chargers are available in a 25A model for most boats and 40A model for larger boats. Each charger will handle three battery banks.

Key Features:

• Pre-programmed to handle common battery types; ready to use with pre-set charge profiles for flooded lead acid, AGM, Gel and TPPL batteries.
• Fully Programmable; user can set charge profile including when to exit absorption stage to match manufacturer specifications and prevent overcharging batteries
• Remote Available: Yes (Model 13908868)
• Pre-Float; fourth stage that holds smaller batteries in a float like stage while larger batteries complete absorption stage. Increases lifespan of smaller batteries.
• Charge Coordination; works with automatic charge relays (ACR) to maintain battery bank separation during charging
• Two Sizes; 20A model for 60-330 Ah battery banks, 40A model for 60-440 Ah battery banks
• Universal Voltage; compatible with 90V-265V AC and 45-65 Hz for worldwide applications
• Easy to Read Digital Display; alerts user to faults. Intuitive programming in several languages. Phone tech support available
• Made in the USA
• Five-year warranty

Specifications		7522
Total Output Current		40A
Input AC Current		3.75A @ 200V AC, 7.5A @ 100V AC
Maximum Output Voltage		16.0V DC
Nominal Voltage		12V DC
Ignition Protected		Yes
Number of Outputs		1 negative
		3 positive
Universal AC Input Voltage		90-265V AC
AC Input Frequency		45-65Hz
Output Voltage Accuracy		0.05V
Typical Float Voltage		13.5V DC
Minimum Operating Temperature		-20° C
Maximum Operating Temperature		70° C
Minimum Storage Temperature		-30° C
Maximum Storage Temperature		80° C
Battery Types		Flooded Lead Acid, AGM, Gel, TPPL (thin plate pure lead)
Recommended for Battery Bank Sizes		60Ah Minimum, 440Ah Maximum
Warranty		5 Year
Height		13″
Width		8 7/16″
Depth		3 5/8″
Documentation		Instructions
Width		8 7/16″
Depth		3 5/8″
Documentation		Instructions

Dimensional Drawing
